主要用途
適用于將礦石類藥材如：赭石、磁石、鐘乳石及貝売類藥材如：杜蠣、珍珠母等鍛制紅透、酥脆。

Main uses
suitable to calcine ore type medicine、ocher、or shells into required herb.

主要特點
可自動控溫.耐熱溫度高.煅制效果好.設備維護性好，使用成本低.符合GMP要求.

Main technical characteristics
The temperature can be adjusted according to different requirements, and the herb can be heated in the very heated situation, thus good calcining result can be achieved. And it is very easy to operate and maintain the machine. Thus it could meet the requirements of GMP.

主要技術參數 Main technical parameter

型號 Type	生產能力 Capacity (kg/h)	料車尺寸 Cart dimension (L)	料車數量（個） Cart number	功率 power (KW)	外形尺寸 dimension (mm)	總重量 weight (kg)
DY18	30~50	620x260x260	1	18	1700x1350x2050	1100
DY45	100~200	520x540x300	2	45	2000x1600x2200	3200
